@surdeddd/bottom-sheet

Universal, headless bottom-sheet engine. One core, eight adapters, GPU-accelerated, fully tested.

A framework-agnostic bottom-sheet primitive. Spring physics, Pointer Events, GPU-only motion, full keyboard a11y, hardware-back interception, multi-sheet stacking — and the exact same engine behind every adapter.

🚀 Live demo → bottom-sheet-demo-ashy.vercel.app

📚 API reference (typedoc) → surdeddd.github.io/BottomSheet

What it does

Every item below is verifiable in this repo's src/:

• 8 build targets — React, Preact, Vue 3, Svelte 5, Solid, Qwik, Web Component (Lit-compatible <bottom-sheet>) and the vanilla core, plus an /overlay subpath (standalone slide-up panel).
• 4 axes — bottom, top, left, right (via mode).
• Spring physics with velocity carry, plus pointer-type-aware tuning (separate touch / mouse / pen drag thresholds).
• Hardware-back interception on Android — opt-in via closeOnBack.
• env(safe-area-inset-*)-aware padding so action rows clear the home indicator.
• WCAG 2.1 AA keyboard slider — Arrow/Home/End/Esc stepping, focus trap with restore.
• Multi-sheet stacking plus a typed sheet-manager registry.
• Cancelable before-snap / before-close — veto a transition synchronously.
• Backed by 500+ unit tests across the suite and ~200 Playwright e2e runs across three browser engines (mobile-chrome / mobile-safari / firefox).

Install

npm i @surdeddd/bottom-sheet
Copy

React / Vue / Svelte are listed as optional peer deps — install only the framework you use, the bundle pays only for that adapter.

Quick start

React

import { BottomSheet } from '@surdeddd/bottom-sheet/react';
import '@surdeddd/bottom-sheet/styles';

<BottomSheet
  snapPoints={[
    { id: 'minimized', size: 96 },
    { id: 'half', size: '45dvh' },
    { id: 'full', size: '85%' },
  ]}
  initial='minimized'
  animation='spring'
  spring={{ stiffness: 260, damping: 28 }}
  focusTrap
  closeOnEscape
  header={<h2>Search vehicles</h2>}
>
  <YourList />
</BottomSheet>;
Copy

Full React docs →

Vue 3

Copy

Full Vue docs →

Svelte 5


Search



Copy

Full Svelte docs →

Web Component (any framework)

<link rel="stylesheet" href="/styles.css" />
<script type="module" src="/element.js"></script>

<bottom-sheet
  snap-points='[{"id":"min","size":96},{"id":"full","size":"85%"}]'
  initial="min"
  animation="spring"
  focus-trap="true"
>
  <h2 slot="header">Search</h2>
  <ul>
    ...
  </ul>
</bottom-sheet>
Copy

Full Web-Component docs →

CDN — no bundler, no install

Drop-in usage from a static HTML page. The IIFE bundle registers <bottom-sheet> as a side effect — no JS glue required.

<!-- CDN, no bundler -->
<link
  rel="stylesheet"
  href="https://unpkg.com/@surdeddd/bottom-sheet/dist/styles.css"
/>
<script src="https://unpkg.com/@surdeddd/bottom-sheet/dist/element.iife.global.js"></script>
<bottom-sheet
  snap-points='[{"id":"min","size":96},{"id":"full","size":"85%"}]'
  initial="min"
>
  <h2 slot="header">Title</h2>
  <p>Content</p>
</bottom-sheet>
Copy

Vanilla core (no framework)

import { BottomSheetEngine } from '@surdeddd/bottom-sheet';
import '@surdeddd/bottom-sheet/styles';

const engine = new BottomSheetEngine({
  element: document.querySelector('.bs-sheet'),
  handle: document.querySelector('.bs-handle'),
  scrollContainer: document.querySelector('.bs-content'),
  backdrop: document.querySelector('.bs-backdrop'),
  snapPoints: [
    { id: 'min', size: 96 },
    { id: 'full', size: '85%' },
  ],
  animation: 'spring',
});
engine.snapTo('full');
Copy

Full vanilla docs →

API at a glance

Snap points

type SnapPoint =
  | number // pixels
  | `${number}%` // percent of viewport along the axis
  | 'fit' // natural height of the whole sheet (handle + header + content + footer)
  | 'content' // alias of 'fit'
  | 'full' // 100 % of axis
  | string; // any CSS length — "50dvh", "clamp(200px, 60%, 800px)"
Copy

Engine options

Option	Default	What it does
snapPoints	required	Ordered list of { id, size }
allowed	all ids	Subset the sheet may settle on right now
initial	first allowed	Snap id to start at
mode	"bottom"	bottom, top, left, right, or logical start / end; reactive in React and Vue adapters
animation	"spring"	spring, tween, ios-spring, material-bounce, linear, snappy
settleAnimation	off	"waapi" — settle runs as a compositor-driven Web Animation (pre-sampled spring keyframes); falls back to rAF automatically
features	all defaults	EngineFeature[] — override/extend the composable feature set (see Slim core below)
spring	snappy	{ stiffness, damping, mass }
flickVelocity	0.65 px/ms	Mobile flick threshold
dragThreshold	18 px	Below this, drag snaps back
rubberBand	true	iOS-style soft over-drag
backdropRange	[0, 1]	Progress range over which backdrop fades
screenRange	[0, 1]	Progress range over which the screen/scrim content fades
focusTrap	false	Trap Tab focus inside the sheet when open
initialFocus	first field	Element / selector to focus on open; false focuses the sheet container (tabindex=-1) instead — avoids the iOS keyboard
closeOnEscape	true	Listen for Escape and close
closeOnBack	false	Intercept Android back button (history.popstate)
closeOnRouteChange	false	Close when the URL changes (patches pushState/replaceState + popstate)
lockBodyScroll	true	iOS-safe body lock (position: fixed)
stackEffect	false	iOS card-stack: back sheets scale down per depth
inertSiblings	false	Mark page siblings inert while open (full modal)
persistent	false	Block dismissal (backdrop / Escape / back); programmatic close() still works
disableClose	false	Block all closing, including programmatic
disableDrag	false	Suppress the drag gesture (imperative snaps still work)
dragFrom	"handle"	Which regions start a drag: "handle", "sheet" (whole sheet), or "zones" (only [data-bs-drag] subtrees). Defaults to "sheet" when no handle is given. [data-bs-no-drag] opts a subtree out in every mode. Also setDragFrom() / getDragFrom() — switching remounts the gesture, no component remount
dragFromContent	true	Whether a touch gesture on the scroll container drags the sheet; override per snap point with { id, size, dragFromContent: false }. Also setDragFromContent()
fitContentToSnap	false	Keeps the whole scroll container reachable and the footer on screen at every snap point, not only the largest. Off by default; see Content reachable at every snap
radius	token default	Corner radius (string CSS length or number px); also setRadius()
maxHeight	none	Cap the sheet height. number (px) or a string ("92dvh", "50%") re-resolved on viewport / orientation changes
returnFocusTo	opener	Focus target on dismiss — an HTMLElement, a selector string, or a () => HTMLElement factory

Anchored elements, docked bars & scrim stages

Pin UI around the sheet — it rides the motion on the compositor (zero JS per frame) and shows/hides per state with configurable animations:

engine.addAnchor({
  element: closeBtn,
  position: 'sheet-top-right', // rides the sheet edge; 9 screen positions too
  showOn: ['half', 'full'],    // snap ids or a predicate
  animation: 'pop',            // fade | scale | slide | pop | custom keyframes
});

engine.addAnchor({
  element: tabBar,
  position: 'dock-bottom',     // full-width bar; the sheet slides under it
});

engine.setScrimStages({
  stages: [
    { for: 'peek', element: teaser },
    { forRange: [0.5, 1], element: expanded },
  ],
  animation: 'fade',
});
Copy

Full anchors & stages docs →

Events

engine.on('snap', ({ id, size, progress }) => {}); // settled state change
engine.on('open', ({ id }) => {}); // 0 → >0 (enter starts)
engine.on('opened', ({ id }) => {}); // enter settled
engine.on('close', () => {}); // → 0 (exit starts)
engine.on('closed', () => {}); // exit settled
engine.on('dragstart', ({ size }) => {});
engine.on('drag', ({ size, delta }) => {}); // ~60 fps — payload is pooled, don't retain
engine.on('dragend', ({ size, velocity }) => {});
engine.on('progress', ({ value, size }) => {}); // ~60 fps

// Cancelable — call cancel() synchronously to veto the transition:
engine.on('before-snap', ({ id, size, previousId, cancel }) => {});
engine.on('before-close', ({ reason, cancel }) => {}); // reason: programmatic | backdrop | escape | back
Copy

Imperative

engine.snapTo('half');
engine.open(); // → first allowed snap with resolved size > 0
engine.close(reason?); // → first snap that resolves to size 0, else first allowed
engine.expand(); // → largest allowed snap
engine.collapse(); // → smallest allowed snap with size > 0
engine.setAllowed(ids, snapId); // dynamic allowlist
engine.setSnapPoints(points); // re-measure
engine.recompute(); // re-measure a 'fit' / 'content' snap on demand
engine.getResolvedSnaps(); // → [{ id, size }] resolved to pixels right now
engine.setPersistent(bool); // toggle persistence (block dismissal) at runtime
engine.setDisableClose(bool); // toggle close-blocking at runtime
engine.setDisableDrag(bool); // toggle the drag gesture at runtime
engine.setRadius('28px'); // corner radius
engine.setMaxHeight('92dvh'); // height cap (re-resolved on viewport change)
engine.canDismiss(); // false when persistent / disableClose
engine.isTop(); // top of the multi-sheet stack?
engine.depth(); // open sheets above this one
engine.destroy(); // remove listeners + cancel animation
Copy

initial starts the sheet born open at any snap whose size resolves > 0 (no open / opened event fires — there is no transition to announce). Calling open() / snapTo() synchronously in the mount tick is safe — no requestAnimationFrame / nextTick delay is needed, including fit / content and teleported sheets. A sheet mounted hidden (display:none ancestor) heals and emits its open sequence once on reveal. See Architecture → Opening at construction.

Scrim runtime API

The scrim is the dim layer behind/around the sheet (screenComponent). All scrim properties can be mutated at runtime — no remount needed.

Method	Purpose
`setScrimMode('full' \	'above-sheet' \	'off')`	Switch positioning at runtime. 'off' fully disables the scrim layer.
setScrimEnabled(boolean)	Convenience switch — stashes/restores opacity ranges.
setScrimTapToClose(boolean)	Install/teardown click-to-close on the scrim.
`setScrimColor(color \	null)/setScrimBlur(blur \	null)`	Live color & backdrop-filter blur. null clears.
setScrimInteractive(boolean)	Toggle pointer-events on the scrim layer.
setBackdropRange([s, e]) / setScreenRange([s, e])	Opacity-range mapping (progress 0..1 → opacity 0..1).
setScrim({ ... })	Batch — applies preset + individual fields in one pass with a single applySize.
setScrimOverlay({ children, position, interactive })	Inject a positioned floating element into the scrim area. Returns a teardown. Useful for monitoring-style "dim everything except this badge" UX.
getScrimState()	Read-only { mode, enabled } snapshot. Stable public API for introspection without coupling to internals.

Presets: 'subtle' | 'standard' | 'monitoring' | 'cinematic' — use via scrimPreset constructor option or setScrim({ preset }).

Overlay runtime API

The overlay engine (@surdeddd/bottom-sheet/overlay) is a standalone slide-up panel that mirrors the scrim's runtime-mutability story for content.

Method	Purpose
`setOverlayChildren(node \	fragment \	factory)`	Replace overlay contents at runtime. Pass a Node, a DocumentFragment, or a () => Node factory.
clearOverlayChildren()	Remove any injected content.
setOverlay({ children, ... })	Batch update — children is one of the accepted fields alongside positioning/preset overrides.

Presets: OverlayPreset is 'sheet' | 'dialog' | 'sidebar' | 'toast' — exposed as the OVERLAY_PRESETS const map and accepted by setOverlay({ preset }).

Sheet manager (route-based registry)

import { createSheetManager } from "@surdeddd/bottom-sheet";

const sheets = createSheetManager<"home" | "marker" | "panorama">({
  home:   { snapPoints: [...], allowed: ["min", "half", "full"], onOpen: loadHome },
  marker: { snapPoints: [...], allowed: ["half", "full"],         onOpen: focusMarker, onClose: blur },
});

// In your route watcher:
sheets.transition(prev, next);
const cfg = sheets.resolve(currentRoute); // typed!
Copy

Performance

Three deliberate choices keep things 60 fps even on mid-range Android:

1. Transform-based positioning. The sheet's height is set once to the largest snap; size changes apply via transform: translate3d(...). Stays on the compositor — zero layout per frame.
2. Spring sub-stepping with single DOM write. Stiff springs integrate at 240 Hz internally for stability, but the engine writes to the DOM exactly once per requestAnimationFrame.
3. Settled-state-only React snapshot. useSyncExternalStore refreshes only on snap / dragstart / dragend. Drag pixels and animation frames propagate via CSS variables (--bs-progress, --bs-size) and direct imperative subscriptions — no React re-renders on every frame.

Slim core & composable features

The default BottomSheetEngine ships every optional behavior preinstalled. If you only need the essentials, import the slim core (~17.5 KB gzip vs ~23 KB) and register just the features you use:

import { BottomSheetCore } from '@surdeddd/bottom-sheet/core';
import { routeFeature, contentSwipeFeature } from '@surdeddd/bottom-sheet/features';

const engine = new BottomSheetCore({
  element, handle, snapPoints,
  closeOnBack: true,
  features: [routeFeature(), contentSwipeFeature()],
});
Copy

Optional features: routeFeature() (closeOnBack / routedTo / closeOnRouteChange), visualViewportFeature() (soft-keyboard clamp), contentSwipeFeature(), persistFeature(), autoCollapseFeature(). Everything else (gestures, snap math, resize self-heal, a11y slider, focus trap, scroll lock, scrim, stacking) is core. Setting an option whose feature is missing dev-warns once and is ignored in production. Custom features implement { name, install(ctx) } — the same seam the built-ins use.

WebGL renderer (opt-in)

import { webglRenderer } from '@surdeddd/bottom-sheet/webgl';

const engine = new BottomSheetEngine({
  element, handle, snapPoints,
  features: [webglRenderer({ jelly: 0.6 })],
});
Copy

Paints the sheet surface — panel, radii, shadow, edge sheen — on the GPU. The moment a drag starts, the sheet's text is lifted into a texture so the whole sheet bends as one surface, and handed straight back to the DOM once it settles. Layout, scrolling, gestures and the accessibility tree never leave the DOM. 4.2 KB gzip, and only if you import it. Falls back to the DOM renderer, silently and mid-session if it has to, when there is no WebGL, under prefers-reduced-motion, or when the browser drops the GL context.

Full WebGL docs →

Debug overlay

import { attachDebugOverlay } from '@surdeddd/bottom-sheet/debug';

const detach = attachDebugOverlay(engine);
Copy

A fixed dev panel showing the active snap, live size/progress, drag/animate flags and the resolved snap list — driven purely by public engine events, shipped as its own entry so it costs nothing in app bundles.

Qwik SSR

The package declares a qwik field pointing at dist/qwik-lib/index.qwik.mjs. Qwik apps pick the adapter up automatically as a vendor root: the consumer optimizer segments it into QRL chunks and renderToString emits a resumable (q:container="paused") sheet. No extra configuration — import { BottomSheet } from '@surdeddd/bottom-sheet/qwik' keeps working for CSR, and Qwik City SSR now works out of the box.

Theming

All visuals are driven by CSS custom properties. Override anywhere:

.bs-root {
  --bs-surface: #18181b;
  --bs-handle-color: #71717a;
  --bs-radius: 28px;
  --bs-shadow: 0 -8px 30px rgba(0, 0, 0, 0.6);
}
Copy

The engine writes --bs-progress (0..1) and --bs-size (px) to the sheet element — drive any CSS animation from drag without touching JS:

.fab {
  transform: scale(calc(1 - var(--bs-progress) * 0.3));
}
.map-canvas {
  filter: blur(calc(var(--bs-progress) * 8px));
}
.search-input {
  opacity: calc(1 - var(--bs-progress));
}
Copy

z-index is engine-owned. The stack controller rewrites inline z-index on .bs-sheet, .bs-backdrop and anchor wrappers on every stack change (base 100, step 10 per depth), so a value you set is overwritten and races the stack. To position the sheet layer against app UI, move the container (teleport target / .bs-root parent) or change the open order — don't style z-index on bs-managed elements. See Architecture → z-index & the sheet stack.

Every sheet owns its backdrop. Open a list, then a detail sheet over it, and both backdrops stay live: the dimming deepens with each level, and the sheet underneath stays masked for the whole time the one above it closes, so taps never reach the page mid-animation. Each backdrop follows its own sheet's progress, so a buried sheet that closes clears its own scrim. The stack keeps the order sheets started opening in — a sheet opened while another is still animating stays on top. If you want a single dim level, pass backdrop={false} (:backdrop="false" in Vue) to the sheets you open on top.

Content reachable at every snap

The sheet is always as tall as its largest snap point and is moved with a transform; that is what keeps a drag on the compositor. The cost is that below the largest snap the bottom of the scroll container sits under the screen edge, by exactly largest snap − current size. At a half snap you can scroll, but the last rows never come into view until the sheet is pulled up.

fitContentToSnap closes that gap:

<BottomSheet snapPoints={points} fitContentToSnap>
  <LongList />
</BottomSheet>
Copy

When the sheet settles, the engine writes the hidden amount to --bs-content-inset and the stylesheet shrinks .bs-content by exactly that much, so the scroll container ends at the edge of the screen: the last row, a focused field and the scrollbar all stay in the visible part, and the thumb is sized for what you can actually see. The moment the sheet starts to move, it switches to the full-height container with a spacer of the same size at the end of the list, so the rows below the edge are already laid out when a drag or an animation reveals them. The switch changes the box and the scroll range by the same amount, so nothing on screen moves. That is one layout when motion starts and one when it settles, none per frame, so the motion stays transform-only. While the sheet moves, a list that was scrolled to its very end is held in place on screen instead of riding up with the sheet and dropping back at the end.

The footer has the same problem and gets the same cure. It is the last thing in the sheet, so below the largest snap it sits under the screen edge along with the end of the list. With fitContentToSnap on, the shrunken container puts the footer at the bottom of the visible part of the sheet at rest, and while the sheet moves the stylesheet lifts .bs-footer by --bs-size − --bs-max-size, so it rides that edge on every frame of a drag or an animation, still without a layout. The list ends above it, not under it. On a snap too short to hold both, the footer slides under the screen edge instead of covering the handle. The WebGL renderer gets the same layout; while the sheet moves its footer paints the surface colour, and a drag lifts the list into a texture that follows the list's scroll position, so a list held at its end stays put there as well.

Scrolling the list at every snap on touch

Making the end of the list reachable and letting a finger scroll to it are two separate things. By default a swipe that starts on the content drags the sheet until it reaches its largest snap, and only then scrolls the list — the native sheet behaviour. On a mouse or trackpad the wheel scrolls at any snap regardless; on touch it does not. To scroll at a half snap with a finger, hand content swipes to the list and keep the handle (and header) for moving the sheet:

<BottomSheet snapPoints={points} fitContentToSnap dragFromContent={false}>
  <LongList />
</BottomSheet>
Copy

dragFromContent can also be set per snap point, which keeps the native pull-to-expand feel at a small peek and frees the list from half upwards:

const points = [
  { id: "peek", size: 120 },
  { id: "half", size: "50%", dragFromContent: false },
  { id: "full", size: "90%", dragFromContent: false },
];
Copy

It applies to bottom sheets and expects the scroll container to be the growing child of the sheet's flex column, the way .bs-content is. For any other container, data-bs-fit-content on the sheet reads rest or moving and --bs-content-inset holds the hidden amount: shrink the container by it at rest, or pad the end of its content by it while moving. On the slim core add contentFitFeature() from @surdeddd/bottom-sheet/features.

Scrim, blur & high contrast

Token	Default	Region
--bs-scrim-color	transparent	Fill of the scrim layer (.bs-screen)
--bs-scrim-blur	0px	backdrop-filter: blur() applied to the scrim layer
--bs-header-min-height	0px	Minimum height of the .bs-header region

--bs-scrim-blur drives a real backdrop-filter blur on the scrim — set it for a frosted backdrop (or use the monitoring / cinematic scrim presets, which set both color and blur). Under Windows High Contrast / forced-colors the stylesheet ships a @media (forced-colors: active) block so the sheet surface, handle and focus ring stay visible.

Padding & layout

Every region's padding is a token — override or zero it to go edge-to-edge. Defaults match the built-in look. Set the variable on the host / .bs-root / :root; custom properties inherit through the Web Component's shadow boundary, so the same override works for every adapter:

Token	Default	Region
--bs-content-padding	0 16px 16px	scrollable body
--bs-handle-padding	8px 16px 4px	grabber strip (top)
--bs-header-padding	0 16px 8px	header slot
--bs-footer-padding	12px 16px (+ inset)	footer slot

(The footer default is 12px 16px calc(12px + env(safe-area-inset-bottom)) — it keeps action buttons clear of the home indicator.)

.bs-root { --bs-content-padding: 0; }               /* full-bleed content */
.bs-root { --bs-content-padding: 0 24px 24px; }      /* custom insets        */
bottom-sheet { --bs-handle-padding: 0; }             /* Web Component, from the host */
Copy

A maxHeight (prop, or max-height attribute on the element) caps the sheet: a 'content' / 'fit' snap taller than the cap settles flush against the edge and the body scrolls internally — the sheet never lifts off its anchor and --bs-size always equals the rendered height.

Demo

npm run demo
# http://localhost:5173
Copy

The editorial demo showcases the adapters, every gesture, every mode (bottom · top · left · right · overlay), and live engine readouts (active snap, progress, velocity, FPS). EN/RU and light/dark toggles in the corner.

Right-to-left

left and right are physical edges and stay physical. For interfaces that flip with the writing direction, use the logical modes — start and end resolve against the direction that applies to the sheet, so start is the left edge in English and the right edge in Arabic:

new BottomSheetEngine({ element, handle, mode: 'start', snapPoints });
Copy

Full RTL docs →

Browser support

Baseline: Chrome/Edge 80, Safari 13.1 (iOS 13.4), Firefox 72 — set by the ES2020 build target and the APIs the engine cannot work without (Pointer Events, CSS custom properties, ResizeObserver). Everything else, from inert to backdrop-filter to WebGL, is capability-checked and degrades.

Full support matrix →

Testing

npm test                 # 500+ unit tests via vitest + happy-dom
npx playwright test      # e2e via Playwright on mobile-Chrome / mobile-Safari / Firefox
npm run typecheck        # TypeScript --noEmit
Copy

CI runs all three across Node 20.19 / 22 on every PR and tag.

Contributing

1. npm install
2. npm run dev — tsup watch mode
3. npm run demo — Vite dev server with live demo
4. npm test — vitest watch
5. Open a PR with a focused diff. The CI matrix gates merging.

License

MIT — see LICENSE.
